Model : XQ35
Name: Led Wall Washer
Voltage: DC24V
IP66
IK: 06
Size: L1000+W35*H48mm
Housing Material: AL6063+Tempered Glass
Beam: 15°/30°/45*/60°/15*25°/10*60°/15 35°
CRI >80
SDCM <5
Ambient temperature: Tamin=-20 °C, Tamax=55
Luminous efficiency: WHITE 80lm/w,RGBW 40lm/w
RH: 30~80%
Warranty: 3 years

- The lamp body is made of high-strength 6063 aluminum alloy, with good
thermal conductivity and excellent heat dissipation.
- onventional length 1M, 0.5M, 0.3M, other sizes can be customized.


LED Brand
ــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــ
Bridgelux/Cree/Luminus/Sanan/Osram/Lumileds/Hongli...


Driver Brand
ــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــــ
Lifud/Eaglerise/Osram/Philip/Coie/Kegu..
Non Dimmable
0-10V Dimmable
DALI Dimmable
Triac Dimmable
